RGV car
product description
RGV is a rail-driven car. The main structure by the body, electrical control box, conveyor, track, slip line and other components. In the deployment of the system, RGV can automatically transport the cargo unit, the goods from one location to another location, you can achieve a multi-mouth, multi-mouth multi-mouth material transfer,
product features
1) Compared to AGV, RGV is a rail car, which needs to travel on the track, can be monorail, double or curved;
2) high speed and speed, the speed can go to 180m / min or more;
3) can be combined with a variety of equipment, which can be equipped with chain lines, drum lines, robots, etc., to adapt to different conditions;
4) RGV car can have a single station, double-bit response to different work efficiency occasions.
產品性能
序號 | 項 目 | 描 述 |
1 | 主體材質 | Q235 |
2 | 搬運單元數量 | 單工位一個貨物單元，雙工位兩個貨物單無 |
3 | 搬運單元尺寸 | 標準托盤1200*800/1000mm, 料箱600*400或按要求制作 |
4 | 貨物單元重量 | 50～2000kg或按要求制作 |
5 | 運行速度 | 5～180m/min,變頻調速 |
6 | 輸送速度 | 5～30m/min，可選變頻調速 |
7 | 控制方式 | 手動，半自動，聯機全自動 |
8 | 電源電壓 | 國內標準工頻工業用電，3相，380V，50Hz |
10 | 供電方式 | 滑觸線 |
11 | 定位方式 | 激光絕對定位，條碼定位， |
12 | 定位精度 | ±5mm |
